Laboratory 80 Mesh Dry Chickpea Powder Grinder Machine

  • 1
  • 2

Brand Name : Brightsail

Model Number : BS

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 30 sets per month

Delivery Time : 25-30 days

Packaging Details : Wooden case

Product name : Laboratory use 80 mesh fine flour making dry chickpea powder grinder machine

Application : food,chemical,pharmaceutical,etc

Warranty : One year

Capacity : 3-300 kg/h

Fineness : 10-120 mesh

Feed size : <10mm

Material : SS 304/316

Voltage : 220-480 v

Contact Now

Laboratory use 80 mesh fine flour making dry chickpea powder grinder machine

Our BS high speed hammer mill is suitable for grinding dried herbal products, different kinds of spice without high oil content, other food and chemical products. Compared with other common hammer grinders, the biggest difference is that its rotor speed is higher, so this grinder can make finer particle size. It also can be used to make flakes or granules if using knife type as the mill part.

Work method:

Feeding the materials into the grinder by way of the hopper, it will be crushed by the hammer knives inside. Then the powder or granules, flakes will be discharged out due to the centrifugal force. If the particle size is small or big for you, you could change the screen mesh to adjust the fineness.

Main features:

1. Small size and machine structure is simple.

2. Small power and low cost.

3. Can make powder and granules or flakes.

Technical data:

Model BS-180 BS-250 BS-300 BS-350
Feed size(mm)

<10mm(granule)

<15*40*2(leaf)

<10mm(granule)

<15*40*2(leaf)

<10mm(granule)

<15*40*2(leaf)

<10mm(granule)

<15*40*2(leaf)
Grind fineness(mesh) 10-120 10-120 10-120 10-120
Capacity(kg/h) 3-50 10-100 20-200 30-300
Grind chamber diameter(mm) 200 270 330 380
Rotor speed(rpm) 5900/8600 4200/6200 2600/5100 2200/4400
Motor(kw) 2.2 5.5 7.5 11
Overall size(L*W*H)(mm) 840*470*1020 930*600*1200 1000*650*1500 1150*700*1600
Weight(kg) 112 210 296 430

Applications

Laboratory 80 Mesh Dry Chickpea Powder Grinder Machine
